Why X-RAY PCB Inspection is Important
As the complexity of electronic assemblies increases, visual inspection alone cannot ensure performance and reliability. X-RAY PCB Inspection Karad ensures early defect detection, faster troubleshooting, and overall product consistency.
When electronic failures occur due to improper soldering or bridging, X-RAY PCB Fault Analysis Karad helps identify the root cause within minutes. This technology is essential for industries like automotive, defense, medical electronics, and telecommunications, where performance accuracy is non-negotiable.
Key reasons to choose Diagnopein Karad:
-
Detect internal solder voids and short circuits.
-
Reduce rework and improve assembly yield.
-
Accelerate product validation cycles.
-
Achieve greater compliance with global QC standards.
Benefits of X-RAY PCB Inspection
At Diagnopein’s PCB X-RAY Quality Control Karad facility, cutting-edge imaging systems deliver measurable benefits across all production stages. This includes better defect prevention, reduced downtime, and consistent compliance.
Core benefits include:
-
Early identification of hidden defects and cracks.
-
Validation of solder ball attachment and lead alignment.
-
Minimization of production waste through accurate defect mapping.
-
Improved product reliability and safety assurance.
-
Faster X-RAY PCB Repair Services Karad for quick turnaround during production.
By utilizing real-time X-ray data, engineers can adjust assembly lines instantly, thereby maintaining consistent product quality across batches.
How X-RAY PCB Testing Works
The PCB X-RAY Testing Karad process involves placing the circuit board inside a controlled X-ray chamber. A fine X-ray beam penetrates the PCB, capturing high-resolution 2D or 3D images of internal structures. Advanced software assesses solder joints, trace connectivity, and component placement to locate possible flaws.
Testing parameters include:
-
Tube voltage: 80–130 kV (depending on PCB density)
-
Magnification range: up to 500×
-
Spatial resolution: 5 µm – 10 µm
-
Image analysis via automatic fault detection software
Each PCB goes through a standardized testing cycle covering multiple viewing angles for accurate inspection and defect mapping. The data helps our specialized team carry out X-RAY PCB Defect Detection Karad, ensuring every component meets strict quality criteria.
